TeraFlex JL: Alpine Long Arms and Long Arm Brackets (NOT INCLUDED) provide complete alignment adjustability and dependability for maximum performance on JL Wrangler/Unlimited models with 3-6'' lifts.
High-quality, dependable, maintenance-free, factory-style bushings provide excellent NVH damping and ride quality.
MUST be used with Long Arm Bracket Kit (JL 2dr: # 1958002) (JL 4dr: # 1958000) ''" NOT INCLUDED.
Can be added to any existing suspension lift.

WARNING: This product can expose you to chemicals including Di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov/product features_benefits=Alpine Control Arms (Short / Long):
- High-quality, dependable, maintenance-free, factory-style bushings provide excellent NVH (noise, vibration, and harshness) damping and ride quality
JL / JT: Long Control Arms (Alpine/IR) and Long Arm Brackets:
- Adjustable Long Control Arms and Long Arm Brackets (NOT INCLUDED) balance front caster angle and pinion angles as well as optimize rear pinion angle and tune anti-squat geometry for proper suspension alignment on 3-6'' lift kits
- Long Control Arms are constructed from durable 42mm x 4mm (front upper) or 50mm x 5mm (front lower, rear upper, rear lower) wall DOM tube for maximum strength
- On higher lifts, bolt-on Long Arm Brackets (NOT INCLUDED) reposition frame-end control arm mounting points to restore near factory orientation to reduce bushing stress during extreme droop and shock load transferred through the Long Control Arms
- Long Arm Brackets are gusseted and reinforced for superior strength w/ reduced NVH compared to other long arm kits
- Long Arm Brackets feature a premium triple-stage powder coating that provides superior durability and corrosion resistance
- Front Long Arm Suspension Crossmember (NOT INCLUDED) provides additional strength
- Install and drive simple bolt-on installation ''" no welding required
Adjustable Control Arms (all):
- Re-centers axles in the wheel well for proper suspension movement. Can also be used to increase wheelbase
- Full range of movement will not restrict articulation or flex off-road
- Zero maintenance forged threaded joints for smooth quiet flex
- Premium black e-dipped coating on tube and forged rod end housing provides superior durability and corrosion resistance
- Anodized 6061-T6 aluminum clamp collar to secure rod end after length adjustment
- TeraFlex Lifetime Warranty against defects,fitment_info=Vehicle(s):
- JL Wrangler (2-door)
- JL Wrangler Unlimited (4-door)
Specs:
- Lift Height: 3-6''
- Does NOT fit 4-door JL Wrangler Unlimited 4xe hybrid models
Control Arm Specs:
JL / JT: Alpine Long Arm Pair - Front Upper (# 1316520):
- Tube Diameter & Wall: 42mm x 4mm
- Factory Length: 20-1/4''
- Min. Length: 27-3/4''
- Max. Length: 28-7/8''
- Bolt - Axle: 12mm
- Bolt - Frame: 14mm
- Bushing - Axle: OEM
- Bushing - Frame: 611012
JL / JT: Alpine Long Arm Pair - Front Lower (# 1316500):
- Tube Diameter & Wall: 50mm x 5mm
- Factory Length: 24''
- Min. Length: 30-7/8''
- Max. Length: 32''
- Bolt - Both: 16mm
- Bushing - Both: 09-01-201-001
JL: Alpine Long Arm Pair - Rear Upper (# 1316560):
- Tube Diameter & Wall: 50mm x 5mm
- Factory Length: 17-3/8''
- Min. Length: 32-3/4''
- Max. Length: 33-3/4''
- Bolt - Both: 14mm
- Bushing - Axle: 611012
- Bushing - Frame: 611011
JL: Alpine Long Arm Pair - Rear Lower (# 1316540):
- Tube Diameter & Wall: 50mm x 5mm
- Factory Length: 19-3/4''
- Min. Length: 36-1/4''
- Max. Length: 37-3/8''
- Bolt - Both: 14mm
- Bushing - Both: 611011,height=11,installation_time=12 Hours,length=41,product_image_size=Default,product_notes=- Adjustable Long Control Arms (JL: Alpine: # 1316005) (JL: Alpine IR: # 1310505) MUST be used w/ Long Arm Bracket Kit (JL 2dr: # 1958002) (JL 4dr: # 1958000) ''" NOT INCLUDED.
- REQUIRES cutting/removal of factory control arm bracketry to install Long Arm Brackets.
- Alignment REQUIRED.
- Available RockGuard Transmission Skid Plate & Long Arm Crossmember Reinforcement (JL / JT: # 4609100) protects your transmission and reinforces your Front Long Arm Suspension Crossmember. RECOMMENDED, BUT NOT REQUIRED.
- Upgrade your Long Control Arm Bushings: w/ our IR Bushing Kit (JL: 8 Long Arms: # 1952801).
- Does NOT fit 4-door JL Wrangler Unlimited 4xe hybrid models.
Bushing:
- Front Upper (JL / JT - Axle: # OEM) (JL / JT - Frame: # 611012)
- Front Lower (JL / JT: # 09-01-201-001 x 2)
- Rear Upper (JL - Axle: # 611012) (JL - Frame: # 611011) (JT: # 09-01-201-001 x 2)
- Rear Lower (JL: # 611011 x 2) (JT: # 09-01-201-001 x 2)
- Replacement Tool Kit (# 1952900),sw_featured=No,width=13
